Forged Steel Butt-Weld Y-Type Strainer

The Forged Steel Butt-Weld Y-Type Strainer is a simple but essential tool. It removes solid particles from the media. These particles include rust, weld slag, and sand. They can damage downstream equipment like control valves, pump impellers, and instruments. Our Y-type strainer catches these solids with a built-in screen. The Y-shaped body gives a smooth flow path. This means low pressure drop. The butt-weld connection makes it a permanent part of the pipe. There are no gaskets to leak. This strainer is perfect for natural gas stations, pump suction lines, and sampling lines.

Chenxiang makes this Forged Steel Butt-Weld Y-Type Strainer from forged steel. Forged steel is dense and strong. It does not have casting defects. The models are GL61H, GL61W, and GL61Y. Body materials are forged steel A105 (carbon steel), F304/F316L (stainless steel), F22 (chrome-moly steel for high heat), and LCB (low temperature). The connections are BW and SW. The screen is made of 304 or 316L stainless steel. You can choose mesh sizes from 20 to 200 mesh. We help you select the right mesh. The right mesh catches particles but keeps pressure drop low. The hard seal materials are H (Cr13), W (body), and Y (STL). The cover has a reliable seal. You can open it easily to clean the screen on site.

The pressure range is PN16 to PN420 (150LB to 2500LB). The size range is DN15 to DN50 (1/2" to 2"). The working temperature is -29°C to 500°C. This butt-weld Y-type strainer works with compressed air, natural gas, coal gas, LPG, nitrogen, oxygen, hydrogen, steam, flue gas, and other process gases.
